JAZ AP/SP Commode

$1,095.00

Moulded Seat

Molded Seat

  • Made with soft integral-skin foam for comfort and durability
  • Contoured for pressure reduction and to help stabilize the pelvis
  • Built-in sacral / coccyx relief area
  • Front opening seat with side cut-outs for hygiene access

Molded Back Support

Molded Back Support

  • Molded back complies with infec- tion control programs
  • Back height adjustment accommo- dates different user trunk heights
  • Recessed back preserves seat depth
  • Padded armrests flip up for trans- fers and bathing access

Adjustable Axle Plates (JAZ-SP)

Adjustable Axle Plates (JAZ-SP)

  • Fore/aft adjustment of rear wheels improves toilet access and maneu- verability of chair through C.O.G. changes

Commode Pan

Commode Pan

  • Handle and spout makes it easier for attendants to empty contents
  • High gloss surface is easier to wash and disinfect
  • Mounts close to the underside of the seat to reduce splashing

Locking Footrests

Locking Footrests

  • Lock pins keeps footrests attached to chair when they swing out or in for transfers — ideal for health care facilities

Positioning Strap Kits (Option)

Positioning Strap Kits (Option)

  • Chest: provides trunk support and improves hygiene access to user's back
  • Pelvic: helps secure user in place and stabilizes pelvis

Anti-Tippers (Option for JAZ-SP)

Anti-Tippers (Option for JAZ-SP)

  • Provides additional rearward stability
SPECIFICATION JAZ (AP|SP)
SEAT WIDTH
18”
SEAT DEPTH
16”

SEAT HEIGHT

(top of seat to floor)
21.5”

CLEARANCE HEIGHT

(under seat w/o pan)
17.5"
BACK HEIGHT
Adjustable 15" / 17"
ARMREST HEIGHT
9.5"

WIDTH BETWEEN

ARMRESTS PADS
18.5”
LATERAL ADJUSTMENT
2” vertical
1” fore/aft
0.5-1.5” offset
FOOTREST ADJUSTMENT
(from seat to footplate)
16”- 20.5”
CASTER TYPE AND SIZE
Two dual-locking 5" front casters

REAR WHEELS

(molded hand rims)
22"
OVERALL WIDTH
22.5” | 25” (outside hand rim)
MAX. OVERALL LENGTH
w/ FOOTRESTS
37” | 38.5” - 42”
OVERALL LENGTH
w/o FOOTRESTS
27.5” | 30” - 32.5”
WEIGHT CAPACITY
250 lbs.
PRODUCT WEIGHT
30 lbs. | 42 lbs.
FRAME MATERIAL
& HARDWARE
Aluminum
Two year limited warranty on the frame against manufacturing defects One year on all other components subject to normal wear and tear exclusions.



SPECIFICATION JAZ-AP (Attendant Propelled)
SEAT WIDTH
18”
SEAT DEPTH
16”

SEAT HEIGHT

(top of seat to floor)
21.5”

CLEARANCE HEIGHT

(under seat w/o pan)
17.5"
BACK HEIGHT
Adjustable 15" / 17"
ARMREST HEIGHT
9.5"

WIDTH BETWEEN

ARMRESTS PADS
18.5”
LATERAL ADJUSTMENT
2” vertical
1” fore/aft
0.5-1.5” offset
FOOTREST ADJUSTMENT
(from seat to footplate)
16”- 20.5”
CASTER TYPE AND SIZE
Four dual-locking 5" casters

REAR WHEELS

(molded hand rims)
N / A
OVERALL WIDTH
22.5" w/ std. arm pad
MAX. OVERALL LENGTH
w/ FOOTRESTS
37"
OVERALL LENGTH
w/o FOOTRESTS
27.5"
WEIGHT CAPACITY
250 lbs.
PRODUCT WEIGHT
30 lb.
FRAME MATERIAL
& HARDWARE
Aluminum
Two year limited warranty on the frame against manufacturing defects One year on all other components subject to normal wear and tear exclusions.



The new JAZ line of rehab shower commode chairs from Raz Design offers simplified, functional positioning and comfort at an entry-level cost.

The new JAZ line of rehab shower commode chairs from Raz Design offers simplified, functional positioning and comfort at an entry-level cost.
